Vertical Vacuum Pre-sealing Machine (Mk-my150l)
Application range
This equipment is applied to the pre-evacuation and hot-press sealing of the pouch lithium battery cell after the electrolyte injection and standing, and at the same time, the vacuum cavity can also be set as the vacuum standing function.
Function features
1) The vacuum degree is maintained well to control the moisture content of the battery finished product.
2) Using a hard sealing method, with good temperature uniformity and high packaging consistency.
3) The overall design is compact and convenient for maintenance.
Technical parameters
| Series | Name | Parameters |
| 1 | Power source |
Single phase AC220V±10%, 50HZ, 1.5kw |
| 2 | Air source | 0.5~0.8Mpa compressed air |
| 3 | Suitable cells | Max.L190*W140*H10 mm |
| 4 | Thickness of batter | Max.10m |
| 5 | Length of sealing hea | 220mm |
| 6 |
Width of sealing edge |
4~10mm, customize according to the requirements. |
| 7 |
Temperature of sealing edge |
Max.250℃, adjustable, accuracy ±3℃ |
| 8 | Time of sealing edge |
0-99S Adjustable |
| 9 | Vacuum degree |
Adjustable, No less than the highest-95KPa |
| 10 | Equipment dimension |
L500*W470*H780mm |
| 11 | Equipment weight | Around 90Kg |
FAQ
Q:Do you provide after-sales service?
A:Yes, our engineers available to service machinery overseas.
Q: What quotation to use?
A:General FOB quotation, other quotations can also be negotiated.
Q: In case of FOB quotation, the factory is responsible for which port to ship to?
A:Shenzhen Port.
Q:Full set of lithium battery equipment, for example:
A:Mixing machine-coating machine-rolling machine-slitting machine-stacking machine-Die cutting machine-welding machine–packaging machine –injection machine–degas machine, etc.
Q:If I want to customize the equipment, how long does it take?
A:We can provide customized services for our customers. It usually takes about 90-120 days, depending on the specifications of the customized equipment.
Q:Are you a manufacturing factory or trading company?
A:We have 3 modern manufacturing factories in Shanghai, Hubei and Dongguan of China.
Q:How to buy?
A:Simply contact our sales and inform your demands, request for a Proforma Invoice. The order will be shipped after receipt of all payment.
Q:How can I trust you?
A:Always warmly welcome for visiting our factory. Or have video call. Or arrange any of your friend to come and help you check our factory. Or any other good idea you can feel free to inform. We will do our best to cooperate. We are serious supplier in this industry for a long time. You can always rely on us.
Q:How is your warranty?
A:12 months trouble-free warranty from the date of acceptance of the equipment, during which the supplier is responsible for free remote guidance maintenance equipment. For the parts that need to be replaced during the warranty period, the transportation cost is paid by the buyer before delivery.
Q:How is your technical support?
A:Online technical support is provided free of charge during the warranty period, and offline technical support is chargeable.
